Karcher HDS 13/20 4S 2900PSI - 21.7L/min Hot Water Pressure Cleaner

Pressure Rating (PSI / Bar):
200 Bar (2,900 PSI) working pressure

Flow Rate (L/min):
10.8 – 21.7 L/min (650 – 1300 L/h)

Power Type:
Electric – 3-phase, 420V, 9.3 kW (50 Hz)

Water Temperature:
Hot water – min 80°C, max 155°C (inlet temp 12°C)

Motor Brand and Type:
4-pole water-cooled electric motor with 3-piston axial pump and SDS (soft damping system) for vibration control

Pump Type:
High-efficiency axial pump with ceramic pistons and turbo blower

Included Accessories:
20 m Longlife high-pressure hose
EASY!Force Advanced trigger gun
1050 mm spray lance
Power nozzle
Servo Control for adjusting pressure and flow
Pole reversing plug (3-phase)
Two-lance operation support

Application Suitability:
The most powerful hot water pressure cleaner in Kärcher’s Super Class – perfect for intensive industrial cleaning where maximum pressure and dual-lance capability are essential

Duty Cycle / Usage Class (Light, medium, or heavy-duty use):
Heavy-duty, continuous industrial use with dual-operator support

Mounting / Portability:
Robust wheeled chassis with roomy onboard storage for cleaning agents, tools, and accessories. Ergonomic layout for left- and right-hand users and dual-lance convenience

Dimensions (L x W x H) (Millimetre):
1330 x 750 x 1060 mm

Weight (kg):
181.5 kg (with accessories)
193.5 kg (incl. packaging)

Safety Features:
Dry-running protection
Stainless steel heating coil (corrosion-resistant)
Electronic service control with LED display
Pressure switch-off
SDS system to absorb pressure surges
Large easy-access fine water filter
Precise exhaust gas monitoring
Integrated LED indicators for fuel, chemical, and maintenance levels
Service switch for water hardness regulation

Warranty & Service Support:
2 years

The Kärcher HDS 13/20-4 S is the most powerful hot water high-pressure cleaner in Kärcher’s renowned Super Class. With a working pressure of 200 Bar and a flow rate of up to 1300 L/h, it is designed for tackling the toughest industrial cleaning jobs, capable of supporting two-lance operation for maximum productivity.

Engineered for durability, this model features a water-cooled, 4-pole electric motor, a three-piston axial pump, and a stainless steel heating coil that resists corrosion and prevents black water build-up. Advanced technologies like eco!efficiency mode, precise detergent dosing, turbo blower, and optimised burner engineering deliver exceptional cleaning power while conserving resources and reducing emissions.

Operational ease is guaranteed with the EASY!Force high-pressure gun, which eliminates holding force by utilising jet recoil, and the EASY!Lock quick-release system, which is five times faster than conventional connections. The large LED display clearly shows levels for fuel, detergent, and maintenance, and service intervals are easy to monitor via the integrated control system.

Designed for the professional who needs uncompromising performance, intuitive handling, and unmatched reliability, the HDS 13/20-4 S is Kärcher’s ultimate hot water pressure cleaning solution.

Click here to view full product specifications
